Feature

Megapixel solutions are the key trend in video surveillance with the advanced benefit of 6-time better image clarity. However, high I/O, huge capacity, and stability of the overall system are major challenges for system integrators. Surveon's Certified Megapixel Recorders, allied with the most qualified partners in the industry, provide a high performance and reliable platform. Built-in with the HW RAID, the EMR6000H secures the multi-channel megapixel recording performance. The industrial grade design of 6 HDD, duo display, and 2 GLAN have made EMR6000H an absolute choice over the commercial PCs and the ideal solution for mission critical projects, such as hotel, school, bank and factory.
  • Optimized Hardware for Megapixel Recording
  • Support 6 Hot-Swappable Hard Drives
  • High Availability and Easy Maintenance
  • In-house Design and Production with 3 Years Warranty
  • Surveon Megapixel Quality Assurance Lab Certificated
  • Pre-load Certified VMS
  • 16 CH D1 H.264 High Profile Encode





Performance Validation

Model
Total
Channels
 Camera
Resolution		 Camera Compression Camera Bit Rate FPS Smart Client
View Mode		 Validation*
EMR6008
8
1080P
H.264
6Mbps
25
8
PASS
EMR6016
16
1080P
H.264
6Mbps
25
16
PASS
EMR6020
20
1.3M
H.264
2 Mbps
25
20
PASS
EMR6025
25
1.3M
H.264
2 Mbps
25
25
PASS

*Remarks:

  • Tested with Milestone XProtect® Essential.
  • RAID 5 rebuild and degrade mode will decrease the recording performance depending on the number of channels.


Recording Days

Number of Channels
2M Cameras*
 Max Recording Days
(12 hrs/day)		 Max Recording Days
(24 hrs/day)
8
1920 x 1080
28
14
12
1920 x 1080
22
12
16
1920 x 1080
15
7
25
1920 x 1080
9
5

*Base on 25 FPS @ 6 Mbps - Tested with Milestone XProtect® Essential.

Professional Megapixel Recorder
EMR6000H
 PC + Software COTS Solution
Hardware
Professional Hybrid NVR
Consumer PC
COTS
Design & Production
100% Own Design & Production
N/A
N/A
QA Validation
Full Tested (Hardware & Software)
N/A
N/A
Low Power
Yes
N/A
N/A
Local Display
N/A
Yes
N/A
Dimension
310(H) x 175(W) x 380(D) mm
360(H) x 165(W) x 392(D) mm
360(H) x 165(W) x 392(D) mm



Hardware Specifications

System Processor Intel® Core i3
System Memory DDR3 4GB
Chipset Intel® Q67 Express Chipset-Embedded
Storage 3.5" SATA HDDs x6;
HDD hot swappable with LED status indicator
Analogue BNC Connector: 16x Video + 16x Audioor
I/O Interface
  • VGAx1; HDMIx1
  • RJ-45: 2x Gigabit Ethernet
  • USB: 6x USB2.0
  • COM: x1
H/W RAID RAID 0, 1, 5
Electrical
  • Input Voltage: 100~240VAC, 3.5A
  • Power Supply: 430W
Operating
Environment
  • Humidity: 5% to 80% (non-condensing)
  • Temperature: 5° to 40°C
LCD Panel Yes
LED Indicator Yes (Fan, Temperature, Power, HDD)
Dimensions 310(H) x 175(W) x 380 (D) mm
Weight 9 kg (w/o HDD)
Certificate BSMI, CB, FCC / CE Class B, UL60959/ IEC 60950, CCC for power only, GOST
